Purpose of Vacuum Electrical Feedthroughs

Matter (liquids and gases) and energy (in the form of electricity or light pulse) must pass from the outside of a vacuum chamber to the inside without any leakages.  There is no pressure loss when a vacuum feedthrough is used, which reduces electrical problems such as voltage drop and contact resistance.

Types of Vacuum Electrical Feedthroughs/ Hermetic Seals

We have designed thousands of vacuum feedthroughs / hermetic seals for customers in a broad range of industries.  We can build feedthroughs for nearly any connector with the flexibility of epoxy resin.  Our range of vacuum feedthroughs are:

Terminology

There are many names for vacuum feedthrough connectors including: electrical feedthrough, epoxy feedthrough, hermetic feedthrough, hermetically sealed feedthrough, glass feedthrough, ceramic feedthrough, hermetically sealed connector.

Flanges and Port Plates

In addition to offering the electrical feedthroughs separately, we also make large flanges and port plates with multiple hermetic feedthroughs mounted to the plate, fully electrically and leak tested and ready for installation.  These large conflat flanges can have tens or hundreds of connectors and wires sealed into them.  This allows you design flexibility to incorporate numerous types of feedthroughs on one flange to achieve the perfect design.

Our design and engineering team will be able to assist you whether you have a requirement for a single vacuum feedthrough or a large quantity of hermetic seals.  If you need assistance designing a hermetic seal for your application, please get in touch and we will provide you with the most cost-effective solution.

Can’t find what you’re looking for?

If you’re unsure of what type of product you need, have a specific requirement, or simply can’t find a particular connector, our friendly in-house experts will be able to assist you.
